Comparison
iO vs Launch Monitor
When you buy through links on Northcourse, we may earn a commission at no additional cost to you. Read the full affiliate disclosure
A side-by-side look at how the Trackman iO and VTrack Launch Monitor compare on specs, accuracy, room requirements, and price. No hype — just the parts of the decision a buyer actually weighs.
Also worth a look
More comparisons with the iO and Launch Monitor
Buy iO
Show all 5 retailersShow fewer retailers
Prices confirmed Nov 10, 2026 · we check every retailer daily
Buy Launch Monitor
Prices confirmed Nov 10, 2026 · we check every retailer daily
When you buy through links on Northcourse, we may earn a commission at no additional cost to you. Read the full affiliate disclosure
Full specificationsEvery spec for both, line by line
Specifications
The numbers, lined up.
Hardware
| Spec | iO | Launch Monitor |
|---|---|---|
| Tracking Method | Hybrid (radar + infrared + high-speed imaging, ceiling-mount) | Photometric overhead (dual 1,800 fps cameras) |
| Indoor/Outdoor | Indoor only | Indoor only |
| Marked Ball Required | No | — |
| Handedness | Both, with nothing to move; Trackman sells the iO DUO for bays under 14 ft wide that need both | — |
| Mounting | — | Ceiling; sensor 8 ft 6 in–9 ft 10 in above the floor |
| Min Ceiling | — | 8 ft 10 in (Laon: 106–122 in floor to ceiling) |
| Room | — | Laon recommends a 213 in (about 17 ft 9 in) wide room and at least 118 in from hitting zone to screen |
| Hitting Zone | — | 31 × 21 in (Laon's page also says up to 31 × 24 in; the smaller is used) |
| Ambidextrous | — | Yes — one install serves left- and right-handed players |
- Tracking MethodiOHybrid (radar + infrared + high-speed imaging, ceiling-mount)Launch MonitorPhotometric overhead (dual 1,800 fps cameras)
- Indoor/OutdooriOIndoor onlyLaunch MonitorIndoor only
- Marked Ball RequirediONoLaunch Monitor—
- HandednessiOBoth, with nothing to move; Trackman sells the iO DUO for bays under 14 ft wide that need bothLaunch Monitor—
- MountingiO—Launch MonitorCeiling; sensor 8 ft 6 in–9 ft 10 in above the floor
- Min CeilingiO—Launch Monitor8 ft 10 in (Laon: 106–122 in floor to ceiling)
- RoomiO—Launch MonitorLaon recommends a 213 in (about 17 ft 9 in) wide room and at least 118 in from hitting zone to screen
- Hitting ZoneiO—Launch Monitor31 × 21 in (Laon's page also says up to 31 × 24 in; the smaller is used)
- AmbidextrousiO—Launch MonitorYes — one install serves left- and right-handed players
Data
| Spec | iO | Launch Monitor |
|---|---|---|
| Ball Data | Full Trackman parameter set, measured spin | — |
| Club Data | Club speed only on the Home tier (1 of 9 club parameters); all 9 need Home Complete | — |
| Data | — | 23 data points: 8 club, 7 ball, 8 ball-flight (Laon's breakdown) |
- Ball DataiOFull Trackman parameter set, measured spinLaunch Monitor—
- Club DataiOClub speed only on the Home tier (1 of 9 club parameters); all 9 need Home CompleteLaunch Monitor—
- DataiO—Launch Monitor23 data points: 8 club, 7 ball, 8 ball-flight (Laon's breakdown)
Software
| Spec | iO | Launch Monitor |
|---|---|---|
| Subscription | Year 1 free; ~$700/yr after; Home Complete tier is +$10,000 up-front and $1,100/yr | — |
| Native Software | Trackman Performance Studio (TPS) | — |
| Included Software | — | VTrack ToolKit + Practice Range — lifetime license |
| Course Play | — | GSPro ($250/yr); E6 Connect (VTrack Home licence, $1,000 one-time with 27 courses, or $300–$600/yr); E6 (2026) $220–$450/yr |
- SubscriptioniOYear 1 free; ~$700/yr after; Home Complete tier is +$10,000 up-front and $1,100/yrLaunch Monitor—
- Native SoftwareiOTrackman Performance Studio (TPS)Launch Monitor—
- Included SoftwareiO—Launch MonitorVTrack ToolKit + Practice Range — lifetime license
- Course PlayiO—Launch MonitorGSPro ($250/yr); E6 Connect (VTrack Home licence, $1,000 one-time with 27 courses, or $300–$600/yr); E6 (2026) $220–$450/yr
Requirements
| Spec | iO | Launch Monitor |
|---|---|---|
| Ceiling Height | 8'10"–10'6" from turf to ceiling, split across Trackman's Low, Mid and High versions (order the one that fits the room); Trackman's setup guide puts the minimum room height at 9'4". Above 10 ft, plan on the VESA drop pole: Trackman's mounting article calls for it above 10 ft, its installation manual above 10'6" | — |
- Ceiling HeightiO8'10"–10'6" from turf to ceiling, split across Trackman's Low, Mid and High versions (order the one that fits the room); Trackman's setup guide puts the minimum room height at 9'4". Above 10 ft, plan on the VESA drop pole: Trackman's mounting article calls for it above 10 ft, its installation manual above 10'6"Launch Monitor—
Room planner
See each one in your sim room.
The planner draws each unit to scale with your room and your swing: where it sits, and whether your swing clears the ceiling, walls and screen. Put in your room once, then switch units in the planner to compare.
Persona fitWho each one is better for
Who each one is better for
Both fit the same buyers.
Neither one wins a persona the other doesn’t. The choice comes down to specs, price, and room fit rather than buyer profile.
Both fit
- Showroom
- Performance Seeker
Build your simulator in two minutes
Five questions. One tailored build with retailer links.
We ask about your budget, your room, and how you’ll use it. We return a complete build — launch monitor, mat, enclosure, projector, software, PC — with the reasoning behind every pick and the alternatives we considered.
